Silicon低損耗晶體,北斗衛星定位晶振,502JCA8M00000CAFR晶振

編號：47836112
頻率：8MHz
尺寸：3225mm

Silicon低損耗晶體,北斗衛星定位晶振,502JCA8M00000CAFR晶振，美國Slicon晶振公司，芯科晶振，包括電壓，工藝，溫度，沖擊，振動和老化。高品質晶振，低損耗晶振，歐美晶振，遙遙領先晶振，室外6G基站晶振，汽車電子晶...

分享到

Silicon低損耗晶體,北斗衛星定位晶振,502JCA8M00000CAFR晶振，美國Slicon晶振公司，芯科晶振，包括電壓，工藝，溫度，沖擊，振動和老化。高品質晶振，低損耗晶振，歐美晶振，遙遙領先晶振，室外6G基站晶振，汽車電子晶振，汽車輔助駕駛晶振，高精度晶振，3225晶振，小體積晶振，MEMS晶振，貼片晶振，Si502振蕩器系列為傳統晶體振蕩器提供單片，基于MEMS的IC替代品。Silicon Laboratories的CMEMS技術將標準CMOS + MEMS結合在單個單片IC中，提供集成，高質量和高可靠性的振蕩器。每個設備都經過工廠測試和配置，以保證性能符合數據表規格。

Silicon低損耗晶體,北斗衛星定位晶振,502JCA8M00000CAFR晶振

參數	標志	試驗條件	最小值	典型的	最大值	單位
頻率范圍	CLK		0.032	—	100	MHz
時鐘周期	CLK	1/FCLK	31,250	—	10	ns
總穩定性	STAB		–20	—	+20	ppm
			–30	—	+30	ppm
			–50	—	+50	ppm
初始精度	F	Measured at 25 ?C at the time of shipping	—	±2	—	ppm
啟動時間	SU	From VDD crossing 1.71 V to first clock output	—	2.5	4	ms
回復時間	RUN	From Sleep mode	—	2.5	5	ms
		From Doze mode	—	1.7	2.55	ms
		From Stop mode5	—	—	1.5 x TCLK + 35	ns
輸出禁用時間	TD	To Sleep/Doze mode, from output running	—	—	225	µs
輸出禁用時間	TD	To Stop, from output running	—	—	1.5 x TCLK + 35	ns
頻率更新時間	NEW_FREQ		—	—	5	ms

Silicon低損耗晶體,北斗衛星定位晶振,502JCA8M00000CAFR晶振

Silicon原廠編碼	生產商品牌	頻率	輸出	電源電壓	頻率穩定度	工作溫度
501AAA27M0000DAF	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±50ppm	-20°C ~ 70°C
501AAA27M0000DAG	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±50ppm	-40°C ~ 85°C
501JAA24M0000DAF	Silicon Labs	24 MHz	LVCMOS	3.3V	±50ppm	-20°C ~ 70°C
501AAA27M0000CAF	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±50ppm	-20°C ~ 70°C
501JAA40M0000CAF	Silicon Labs	40 MHz	LVCMOS	3.3V	±50ppm	-20°C ~ 70°C
501JAA25M0000BAF	Silicon Labs	25 MHz	LVCMOS	3.3V	±50ppm	-20°C ~ 70°C
501HCA27M0000DAF	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501BCA16M0000BAF	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501AAA24M0000BAG	Silicon Labs	24 MHz	LVCMOS	1.7V ~ 3.6V	±50ppm	-40°C ~ 85°C
501AAA27M0000BAG	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±50ppm	-40°C ~ 85°C
501JAA24M0000BAG	Silicon Labs	24 MHz	LVCMOS	3.3V	±50ppm	-40°C ~ 85°C
501JAA40M0000BAG	Silicon Labs	40 MHz	LVCMOS	3.3V	±50ppm	-40°C ~ 85°C
501ACA10M0000BAF	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501JAA25M0000BAG	Silicon Labs	25 MHz	LVCMOS	3.3V	±50ppm	-40°C ~ 85°C
501HCA27M0000BAF	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCA27M0000DAG	Silicon Labs	27 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501BCAM032768BAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501BCAM032768BAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501BCAM032768CAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501BCAM032768CAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501BCAM032768DAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501BCAM032768DAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501JCAM032768BAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCAM032768BAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501JCAM032768CAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCAM032768CAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501JCAM032768DAF	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCAM032768DAG	Silicon Labs	32.768 kHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501HCAM032768BAF	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCAM032768BAG	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501HCAM032768CAF	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCAM032768CAG	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501HCAM032768DAF	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCAM032768DAG	Silicon Labs	32.768 kHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501ABA8M00000BAF	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-20°C ~ 70°C
501ABA8M00000BAG	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-40°C ~ 85°C
501ABA8M00000CAF	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-20°C ~ 70°C
501ABA8M00000CAG	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-40°C ~ 85°C
501ABA8M00000DAF	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-20°C ~ 70°C
501ABA8M00000DAG	Silicon Labs	8 MHz	LVCMOS	1.7V ~ 3.6V	±30ppm	-40°C ~ 85°C
501ACA10M0000BAG	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501ACA10M0000CAF	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501ACA10M0000CAG	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501ACA10M0000DAF	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501ACA10M0000DAG	Silicon Labs	10 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501JCA10M0000BAF	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCA10M0000BAG	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501JCA10M0000CAF	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCA10M0000CAG	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501JCA10M0000DAF	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501JCA10M0000DAG	Silicon Labs	10 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501HCA12M0000BAF	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCA12M0000BAG	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501HCA12M0000CAF	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCA12M0000CAG	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501HCA12M0000DAF	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-20°C ~ 70°C
501HCA12M0000DAG	Silicon Labs	12 MHz	LVCMOS	1.7V ~ 3.6V	±20ppm	-40°C ~ 85°C
501BCA16M0000BAG	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501BCA16M0000CAF	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501BCA16M0000CAG	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501BCA16M0000DAF	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-20°C ~ 70°C
501BCA16M0000DAG	Silicon Labs	16 MHz	LVCMOS	3.3V	±20ppm	-40°C ~ 85°C
501BAA16M0000BAF	Silicon Labs	16 MHz	LVCMOS	3.3V	±50ppm	-20°C ~ 70°C
501BAA16M0000BAG	Silicon Labs	16 MHz	LVCMOS	3.3V	±50ppm	-40°C ~ 85°C
501BAA16M0000CAF	Silicon Labs	16 MHz	LVCMOS	3.3V	±50ppm	-20°C ~ 70°C
